Quiet One® Aquarium Pumps Pro Series

Q1 AQUARIUM LitEven better and quieter than before by as much as 50%

Quiet One® Aquarium Pumps Pro Series

FEATURES

For Submersible or Dry Applications in Salt or Freshwater Aquariums.

  • ECO-SAV runs cooler and generates more power with less energy consumption.
  • Internal recirculation prevents overheating and ejects obstructing debris.
  • Remarkable impeller technology provides combined rotors, improved shaft materials and corrosion resistant bearings.
  • EZ access cover allows ease of maintenance of rotor, shaft and removable impellers.
  • Innovative “cooling chambers” provide air-cooling during dry use and water cooling in wet applications.
  • Flow Controls on 200,400, 800,1200,2200,3000,4000,5000 and 6000 Models.
  • 115V/60 Hz or 220V/50 Hz models available in all sizes.

RESOURCES

Datasheets/Brochures

Q1-AQUARIUM-Lit.pdf

Owner Manuals

Quiet-One-Pump-Instructions.pdf
Replacement Parts Related Images

WHAT'S NEW

Product Specifications

Quiet One Aquarium Pumps 115Volt / 60 Hz / 6′ cord / 2 Wire
Part No. Model GPH Ft. of head Watts Amps Suction Discharge
R440464 200 87 1.8′ 2.9 0.047 Screen 1/2″ Tube
R440465 400 103 2.1′ 3.5 0.047 Screen 1/2″ Tube
R440101 800 240 4.8′ 10.2 0.24 Screen 1/2″ tube
R440102 1200 317 7.0′ 17.5 0.40 1/2″ MPT 1/2″ MPT
R440110 2200 594 10.7′ 38 0.46 1″ MPT 1″ MPT
R440103 3000 758 10.3′ 49 0.54 1″ MPT 1″ MPT
R440104 4000 1022 10.2′ 58 0.60 1″ MPT 1″ MPT
R440106 5000 1458 11.8′ 123 1.20 1″ MPT 1″ MPT
R440107 6000 1876 12.0′ 155 1.50 1″ MPT 1″ MPT
*Combination
Aquarium/Fountain
Package 20′ Cord

Quiet One Aquarium Pump Dimensions
Part No. Model Length Width Height
R440464 200 2 1/4″ 2 1/4″ 4 1/4″
R440465 400 2 1/4″ 2 1/4″ 4 1/4″
R440101 800 2 3/4″ 2 1/2″ 2 1/2″
R440102 1200 3 3/4″ 2 3/4″ 3 1/4″
R440110 2200 6.11″ 4.02″ 4.33″
R440103 3000 6.11″ 4.02″ 4.33″
R440104 4000 6.11″ 4.02″ 4.33″
R440106 5000 7.68″ 4.56″ 5.32″
R440107 6000 7.68″ 4.56″ 5.32″

Quiet One Flow Chart
Pump Model Maximum Flow
GPH		 Minimum Flow
GPH *		 Max Flow
at 1′		 Max Flow
at 2′		 Max Flow
at 3′		 Max Flow
at 4′		 Max Flow
at 5′		 Max Flow
at 6′		 Max Flow
at 7′		 Max Flow
at 8′		 Max Flow
at 9′		 Max Flow
at 10′		 Shut Off
Feet
200 53 35 30 1.64′
400 106 55 71 15 2.13′
800 220 140 189 154 109 36 4.37′
1200 296 175 270 241 210 175 125 20 6.10′
2200 594 404 563 528 493 455 410 361 308 258 188 96 10.66′
3000 819 423 781 731 672 611 540 463 375 291 193 66 10.33′
4000 991 476 937 861 786 712 621 528 408 305 176 25 10.17′
5000 1400 793 1347 1278 1205 1129 1041 906 801 695 590 467 11.65′
6000 1664 819 1592 1514 1419 1321 1214 1070 925 766 587 421 11.65′
*with flow control closed



Certifications



230Volt / 50 Hz Models available
Flow Rate is reduced by 25% to account for loss in filter and plumbing.
Recommended turnover rate in Aquarium fresh water systems is 2 times per hour and Aquarium salt water systems 3 times per hour.
